Handheld Die Mould Laser Welding Machine , 300 Watt Laser Spot Welding Machine

China Handheld Die Mould Laser Welding Machine , 300 Watt Laser Spot Welding Machine supplier
Handheld Die Mould Laser Welding Machine , 300 Watt Laser Spot Welding Machine supplier Handheld Die Mould Laser Welding Machine , 300 Watt Laser Spot Welding Machine supplier

Large Image :  Handheld Die Mould Laser Welding Machine , 300 Watt Laser Spot Welding Machine

Product Details:

Place of Origin: Wuhan,China
Brand Name: Huahai Laser
Certification: CE,FDA
Model Number: HB-YW

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Standard export wooden box packaging
Delivery Time: 10days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100sets/month
Contact Now
Detailed Product Description
Laser Type: Nd:YAG Max. Output Power: 300W/400W
Single Pulse Energy: 90J Pulse Width: 0.3-20ms
Focal Spot Diameter: 0.2-3.0mm Welding Depth: ≤5mm(Determined By Material)
High Light:

mold laser welding machine

,

laser spot welding machine

300w Handheld Die Mould Laser Welding Machine For Stainless Steel Laser Spot Welding


Introduction:



Laser welding a high efficient precision welding method which is in the use of high energy density laser beam as a heat source . Laser welding is one of the important aspects of laser processing technology. Laser radiates and heats the workpiece surface, The surface heat diffuses to the inside through heat conduction, Then the laser makes the workpiece melting and form the specific welding pool by controlling the laser pulse width, energy, peak power and repetition frequency. Due to its unique advantages, it has been successfully applied to the precise welding for micro parts and small parts.
Laser welding is fusing welding technology, laser welder puts laser beam as the energy source, and make it impact on the weldment joints to realize welding .


Features:



1) Ceramic converging cavity is corrosion resistant and high temperature resistant, and has 8-10 years service life. The life of xenon lamp is more than 8 million times.
2) Using the most advanced light shielding system to eliminate the irritation to eyes by light during working.
3) The laser head and optics part can be rotated for 360°,upward/downward lifting and forward/backward pushing, suitable for repairing of large, medium and small moulds.
4) The parameters are controlled by intelligent remote controller, which is simple and convenient.
5) The work bench can be lifted, and moved in three dimensions.
6) The size of light spot can be adjusted.



Application:


laser welder was originally designed for mould industry which apply in molding and repairing of plastic molds, die-casting molds, extrusion molds, glass molds, plastic blow molds, rubber molds, molds of digital products/mobile phone/toy/automobile/motorcycle, also can be used in metal sheet stitching welding, pipe/ tube conjunction welding, and manufacturing of sensor, level switch and fine auto parts, etc.


Specifications:



SPECIFICATIONS FOR OPTICAL FIBER LASER MARKING MACHINE
Model
HB-YW300
HB-YW400
Laser output power
300W
400W
Laser type
YAG pulse
Laser wavelength
1064um
3-axis stroke of work bench
X=300mm, Y=200mm (X,Y can be adjusted manually, Z-axis can be lifted)
Pulse width
0.1ms-20ms
Pulse energy
80J
120J
Pulse frequency
0-50Hz
Size of welding spot
0.2mm-3.0mm
Adjusting range of light spot
1.8mm
Max. bearing of work bench
150KG
Repeating precision of work bench
0.001
Positioning precision of work bench
0.001
Sighting positioning system
HD-CCD monitor system
Cooling method
Water cooling
Max. output power
400W
Integrity power
5KW
Power supply
AC220VAC/380VAC+-15%/50HZ/25A
CNC or not
No
Guarantee
1 year
Sample
Free sample test available


Samples:


Handheld Die Mould Laser Welding Machine , 300 Watt Laser Spot Welding Machine
